Rebec RC90 Midrange Speaker
Natural and Emotional Vocal Reproduction
The Rebec RC90 is a dedicated midrange driver developed for the Rebec RC Series speaker systems. Designed specifically for vocal reproduction, the RC90 focuses on delivering natural tone, emotional expression, and musical realism throughout the critical midrange frequencies.
As the acoustic centerpiece of the RC Series 3-way systems, the RC90 is engineered to reproduce vocals and instruments with convincing presence, helping listeners connect more deeply with the music.
Sound Characteristics
- Natural vocal presentation
- Emotional and expressive midrange reproduction
- Rich vocal texture and body
- Smooth tonal balance
- Engaging musical character
The RC90 is designed to capture the emotion and realism within recordings, allowing vocals to sound more lifelike and involving.
Key Features
Dedicated Midrange Design
Optimized specifically for the vocal frequency range, the RC90 reproduces singers and instruments with excellent presence, clarity, and natural tonal character.
Emotional Vocal Performance
The tuning philosophy of the RC90 prioritizes musical expression and vocal realism, helping reveal subtle nuances and emotional content within recordings.
Balanced and Musical Presentation
Rather than emphasizing analytical detail, the RC90 focuses on creating a natural and enjoyable listening experience with strong musical coherence.
Designed for 3-Way Systems
The RC90 integrates seamlessly with the RC165 mid-woofer and RC25 or RC28 tweeters, contributing to the excellent vocal imaging and musical presentation that define the RC Series.
Performance Highlights
The RC90 is developed for listeners who place vocals at the center of their musical experience. Its natural tonal balance and emotional presentation help create a rich and engaging soundstage where singers and instruments are reproduced with convincing realism.
Application
The Rebec RC90 is ideal for three-way component systems, active DSP installations, and sound quality-focused projects where vocal performance and musical expression are primary priorities.
Summary
The Rebec RC90 is a dedicated midrange driver engineered for natural and emotional vocal reproduction. Combining rich tonal character, expressive musicality, and excellent vocal presence, it serves as the defining element behind the unique sound signature of the Rebec RC Series.
Specification
| Speaker Model | RC90 |
| Type of Speaker | Mid-range |
| Speaker Size | |
| Nominal power (RMS) | 30W |
| Maximum power (PEAK) | 60W |
| Sensitivity (2.83V/1m) | 87dB |
| Frequency response | 75Hz-6KHz |
| Impedance | 4ohm |
| DRC | 3.6ohm |
| Voice coil diameter | 20mm/0.79in |
| Cone (materier) | mica composite paper cone material |
| Surround | Isobutylene Isoprene Rubber |
| Magnet (materier) | Ferrite Magnet |
| Magnet (diameter) | 60mm |
| PARAMETERS | |
| F0 | 105Hz |
| Sd | 26cm² |
| Vas | 1.2L |
| Cms | 1.313mM/N |
| Mms | 1.7g |
| BL | 2.683N/A |
| Qms | 3,941 |
| Qes | 0,575 |
| Qts | 0,502 |
| SPLo | 87dB |
| Xmax | 6mm |
| Xmech | 10mm |
